Suitable for:

• low pressure indoor residential and commercial water heating applications

• maximum operating pressures up to 76 kPa

• left, right, or bottom plumbing connections

Not suitable as a pool or spa heater.

Anode:

Not required

Connections:

Hot and cold water connections ¾ " (20 mm)

Construction:

Inner cylinder: High grade copper
Outer casing: Galvanised steel

Element:

Incoloy stainless alloy steel

Operating pressures:

Maximum inlet pressure = 76 kPa
Maximum working pressure = 76 kPa

Thermal insulation:

CFC-free polyurethane foam, compliant with MEPS standard

Thermostat standard:

7 " Cotherm probe 20 A over-temperature thermostat, manually resettable at 85 °C

Thermostat wetback:

7 " Cotherm probe 20 A (no over temperature

Weights

9L: 7kg empty, 16kg full

14L: 8kg empty, 22kg full

22L: 9kg empty, 31kg full

44L: 11kg empty, 55kg full

90L: 16kg empty, 106kg full

135L: 21kg empty, 156kg full

180L: 26kg empty, 206kg full

225L: 31kg empty, 256kg full

Cylinder recovery times (theoretical)

Based on a thermostat temp. setting of 60 °C and an incoming water temp. of 15 °C.

• 9 L = 32 mins (1 kW)

• 14 L = 49 mins (1 kW)

• 22 L = 1 hr 17 mins (1 kW)

• 44 L = 1 hr 10 mins (2 kW)

• 90 L = 2 hrs 38 mins (2 kW)

• 135 L = 3 hrs 56 mins (2 kW)

• 180 L = 5 hrs 15 mins (2 kW), 3 hrs 30 mins (3 kW)

• 250 L = 4 hrs 51 mins (3 kW)

Compliance

No cylinder wrap required. All Rinnai cylinders meet the NZ Minimum Energy Performance Standard (MEPS).

Warranty: 5 Years
